Form Factor

M.2 2280

Interface

PCIe Gen 4.0 x 4, NVMe 1.4

Capacity

512 GB

1 TB

2 TB

4 TB

Max. Sequential Read Speed

7200 MB/s

7200 MB/s

7200 MB/s

7400 MB/s

Max. Sequential Write Speed

3800 MB/s

6300 MB/s

6300 MB/s

6500 MB/s

Max. Random Read Speed (IOPS)

968 K

990 K

925 K

950 K

Max. Random Write Speed (IOPS)

724 K

997 K

974 K

980 K

Operating Power Consumption (Read)

3.58 W

3.82 W

4.79 W

3.09 W

Operating Power Consumption (Write)

3.3 W

5.18 W

5.67 W

3.16 W

 Idle Power Consumption

0.046 W

0.048 W

0.048 W

0.014 W

Dimensions

80 × 22 × 2.2 mm

Weight

7g ± 1g

MTBF

1,500,000

Working Temperature

-40 °C to 85 °C

Storage Temperature

0 °C to 70 °C

Vibration Resistance

6.0667 GRMS (20-2000Hz)

Certifications

CE, FCC, RoHS, VCCI, RCM, BSMI

Warranty

  5-Year/300 TBW

  5-Year/600 TBW

  5-Year/1200 TBW

  5-Year/2400 TBW
