| SPECIFICATIONS |
| Brand |
Seagate |
| Series |
IronWolf |
| Model |
ST8000VN004 |
| Interface |
SATA 6Gb/s |
| Capacity |
8 TB |
| Form Factor |
3.5" |
| Features and Performance |
| Drive Bays Supported |
1 - 8 Bays |
| Multi-User Technology |
180 TB/Year |
| Rotational Vibration (RV) Sensor |
Yes |
| Dual-Plane Balance |
Yes |
| Error Recovery Control |
Yes |
| Maximum Sustained Transfer Rate OD (MB/s) |
210 MB/s |
| Spindle Speed (RPM) |
7,200 |
| Cache (MB) |
256 |
| Reliability |
| Load/Unload Cycles |
600,000 |
| Non-Recoverable Read Errors Rate, Max |
1 per 10E15 |
| Power-On Hours |
8,760 |
| Workload Rate Limit (WRL) |
180 |
| Mean Time Between Failures (MTBF, Hours) |
1,000,000 |
| Power Management |
| Startup Current, Typical (12V, A) |
1.8 |
| Average Operating Power (W) |
8.8 W |
| Idling Average (W) |
7.6 W |
| Standby Mode/Sleep Mode, Typical (W) |
0.6/0.6 |
| Voltage Tolerance, Inc. Noise (5 V) |
±5% |
| Voltage Tolerance, Inc. Noise (12 V) |
±10% |
| General |
| Operating Temperature Range |
5°C - 70°C |
| Non-Operating Temperature Range |
-40°C - 70°C |
| Shock, Operating 2 ms (Gs) |
70 Gs |
| Shock, Non-Operating 2 ms (GS) |
250 Gs |
| Dimension |
26.11 x 101.85 x 147 mm |
| Weight |
722 g |
| Warranty Information |
| Warranty |
3 Year Limited Warranty |
