Description
Specifications
| Presentation | Easy-to-install, easy-to-operate, easy-to-maintain, and easy-to-service 20 kVA, 400V 3-phase UPS. With advanced product features, competitive specifications, and robust electrical design, the Easy UPS 3S UPS makes business continuity easy for small and medium data centers and electrical rooms. Includes dust filter and conformance-coated boards for harsh environments, and 2 internal 7Ah modular battery strings, expandable to 3 strings for extended runtime. |
|---|---|
| Lead time | Usually delivered within 6 weeks |
| Main Input Voltage | 400 V 3 phase |
|---|---|
| Other Input Voltage |
380 V 415 V |
| Main Output Voltage | 400 V 3 phase |
| Other Output Voltage | 380 V 415 V |
| Rated power [W] | 20kW |
| Rated power [VA] | 20 kVA |
| Equipment provided | Dust Filter Installation Guide |
| Efficiency | View Efficiency Graph |
|---|---|
| Battery Type | VRLA |
| voltage | 240V |
| Maximum short-circuit current | 10 kA |
| Pre-installed battery | 2 |
| Empty battery slot | 1 |
| color | White RAL 9003) |
|---|---|
| high | 140cm |
| width | 38 cm |
| depth | 92.8cm |
| product weight | 446kg |
| USB compatible | Yes |
| Maximum input current | 37A |
|---|---|
| Input voltage total distortion | Under full load conditions, less than 3% |
| Load power factor | 0.9 ahead to 0.9 behind |
| Input Power Factor at Full Load | 0.99 |
| Efficiency at full load | 304...477 V |
| Network frequency | 45...65 Hz |
| Maximum configurable power in VA | 20 kVA |
|---|---|
| Maximum configurable power (W) | 20kW |
| Output frequency (synchronized with mains) |
50 Hz synchronized with mains 60 Hz synchronized with mains |
| harmonic distortion | less than 3% |
| Output voltage total distortion (THD) | < 3% linear load |
| Output voltage tolerance | +/- 1.5% |
| topology | Online double conversion |
| Other parameters | UPS weight does not include battery weight. |
| Product certification | CE EAC RCM |
|---|
| Working temperature | 0…40°C |
|---|---|
| Relative humidity | 0…95 % non-condensing |
| operating height | 0...3333 ft |
| Storage environment temperature | -15…40 °C |
| relative storage humidity | 0…95 % non-condensing |
| Storage height | 0.00…15240.00 m |
| sound level | 60 dBA |
| heat dissipation | 900W |
| IP protection level | IP20 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 164 cm |
| Package 1 Width | 101.4 cm |
| Package 1 Length | 56.3cm |
| Package 1 Weight | 494kg |
| maintainance | 1 year on-site repair or replace with factory authorized Start-Up |
|---|
