Description
Capacity
2TB
Form Factor
M.2 2280
NAND Flash
3D NAND
Controller
IG5236
Dimensions (L x W x H)
80 x 22 x 4.3mm / 3.15 x 0.87 x 0.17inch (with heatsink),
80 x 22 x 3.3mm / 3.15 x 0.87 x 0.12inch (without heatsink)
Weight
10g / 0.35oz (with heatsink),
7g / 0.24oz (without heatsink)
Interface
PCIe Gen4x4
Sequential Read (Max*)
Up to 7400MB/s (PC/Laptop),
Up to 6300MB/s (PS5)
Sequential Write (Max*)
Up to 6800MB/s
4KB Random Read IOPS(Max*)
Up to 750K
4KB Random Write IOPS(Max*)
Up to 750K
Operating Temperature
0°C - 70°C
Storage Temperature
-40°C - 85°C
Shock Resistance
1500G/0.5ms
MTBF
2,000,000 hours
Terabytes Written (TBW)(Max Capacity*)
2960TB
Warranty
5-year limited warranty
