Description
Dimensions
120x120x25mm
Bearing Type
Dual Bearings
Connector
4-Pin PWM
Speed (RPM)
PWM Mode: 900 ~ 2150 RPM ± 10%
DC Mode: 450 ~ 2150 RPM ± 10%
DC Mode: 450 ~ 2150 RPM ± 10%
Fan Max Air Flow (CFM)
75 CFM
Fan Max Static Pressure (mmH2O)
3.15 mm H₂O
Fan Noise Level (dBA)
10-28dBA(Max)
Fan Rated Voltage
DC 12V
Fan Starting Voltage
DC 5V
Fan Operating Voltage
DC 5V～13.2V
Fan Rated Current
0.16A (Max)
Fan Power Dissipation
1.56W
Fan protection
Auto-Restart
MTTF
25℃：250,000 Hours
60℃：60,000 Hours
60℃：60,000 Hours
Cable length
620 ± 10mm Total
Including a 450mm Extension Cable
Daisy-Chain Capable
Including a 450mm Extension Cable
Daisy-Chain Capable
Weight
Product：210g (7.4oz)
with Package：230g (8.1oz)
Warranty
5 years
