Description
Basic specifications
automatic document feeder
20 pages
Speed Dial
200 stations
Warranty
one year
fax
compatibility
ITU-T Super Group 3
Modem speed
33,600 bps (with automatic fallback)
scan width
208 mm
Print width
208 mm
Grayscale
8-bit/256 levels
horizontal resolution
8 dot/mm
standard
3.85 line/mm
fine
7.7 line/mm
7.7 line/mm
Super fine
15.4 lines/mm
ONETOUCH knob
22 stations
group
Max. 8
broadcast
272 locations
automatic redial
3 times at 5-minute intervals
memory transfer
400 pages
paperless reception
400 pages
File size
width
147.3 mm to 215.9 mm
length
147.3 mm to 355.6 mm
Display, connectivity and memory
LCD (liquid crystal screen)
16 characters × 2 lines
memory capacity
16 MB
USB
Hi-Speed USB 2.0.
Use a Type A/B USB 2.0 cable no longer than 2 meters.
copy
Color/Black and White
Monochrome
copy width
204mm
multiple copies
Up to 99 pages
Zoom out/zoom in
25% to 400%
Home page copy output time
Less than 12 seconds
printer
Resolution
2,400 dpi × 600 dpi, 600 dpi × 600 dpi
Printing speed
20 pages/minute (A4 size)
Home print output time
Less than 10 seconds
Printing method
Electrophotographic laser printer
Copy resolution
300 dpi × 600 dpi
Print media
Paper input tray paper type
Plain, thin or recycled paper
Paper input tray paper size
Letter, A4, B5 (ISO/JIS), A5, A5 (Long Edge), B6 (ISO), A6, Executive (legal or folio for Asia)
Paper input tray paper weight
60 gsm to 105 gsm
Paper input tray maximum tray capacity
Up to 250 photos
Paper input manual feeder paper type
Envelope, labels, thin paper, thick paper, recycled paper, bond paper or plain paper
Paper input manual feeder paper size
Width: 76.2mm to 216mm
Length: 116 mm to 406.4 mm
Paper input manual feeder paper weight
60 gsm to 163 gsm
Paper input manual feed tray maximum tray capacity
One sheet at a time, 80 gsm plain paper
Paper output print side down output tray
100 sheets
Paper output print side down output tray
One sheet (face-up print delivery to the face-up output tray)
operate
power supply
AC 110~120V,50/60Hz
Peak power consumption
Approximately 1,080 W at 25°C
Copying power consumption
Approx. 420 W at 25°C
Standby power consumption
Approx. 55 W at 25°C
Deep sleep power consumption
About 1.5W
weight
9kg
Noise level (sound power) when printing
L wa d = 6.18 dB (A)
Noise level in standby
L wa d = 4.25 dB (A)
Noise level (sound pressure) when printing
L pa m = 53 dB (A)
Noise Level Sound Pressure Standby
L pa m = 30 dB (A)
operating temperature
10°C to 32.5°C
Storage temperature
0°C to 40°C
Operating humidity
20% to 80% (without condensation)
Storage humidity
10% to 90% (without condensation)
