Description
Technical specifications
Technical information
Diagonal visible size
39.7" Default display area (horizontal x vertical)
929.28 mm x 392.04 mm 36.59" x 15.43" 364,314.9 mm 2 (564.69 in 2 ) Panel type
IPS Black technology Monitor screen coating
Use 3H hard coating to provide anti-glare function Default maximum resolution
5120x2160 (120Hz) perspective
178 ° Vertical/178 ° level point distance
0.1815 mm x 0.1815 mm Pixels per inch (PPI)
140 contrast ratio
2000:1 (standard value) curvature
2500R aspect ratio
21:9 backlight technology
LED edge-lit system brightness
450 cd/m 2 (standard value)600 cd/m 2 (HDR peaking)
Reaction time
8 ms (normal mode)5 ms (fast mode)
Equipped with HDR technology
Yes, VESA DisplayHDR600 ambient light sensor
Yes, automatic brightness and color temperature adjustment Connection options
- 1 HDMI (according to HDMI 2.1 specified specifications, supports up to 5K2K 5120 x 2160 120 Hz FRL, HDR static relay data, VRR)
- 1 DP 1.4 (HDCP 2.3) (up to 5120 x 2160 120 Hz, HDR, DSC)
- 1 ThunderboltTM 4 downstream ports (15W), suitable for daisy chain topology (video + data)
- 1 ThunderboltTM 4 (140W) (equipped with DisplayPort 1.4 alternative mode, SuperSpeed USB 3.2 Gen 2 (10 Gbps) upstream port, supports up to 140W USB PD fast charging)
- 1 USB Type- C® upstream port (data transfer only, SuperSpeed USB 10 Gbps, USB 3.2 Gen 2)
- 4 USB Type-A downstream ports (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2)
- 1 audio line output
- 1 RJ45 (2.5 GbE) Quick access:
- 1 USB Type-A downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) with BC1.2 charging function
- 2 USB Type- C® Downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) with 15W charging capability
Adjustability
Height, tilt, left and right rotation adjustable height
150mm tilt
-5 ° /+21 °
Rotate left and right
-30 ° /+30 °
PbP/PiP
have Keyboard, screen and mouse (KVM)
have Daisy chain availability
have audio output
1 audio line output Built-in speaker
2 pcs 9W Dell Display Manager Compatibility
Yes, provides EasyArrange and other important functions Color gamut
DCI-P3 99%, Display P3 99%, sRGB 100%, BT.709 100%, DCI-P3, Display P3, sRGB and BT.709: Delta E< 2 (Average) Color support
1.07 billion colors (8-bit + A-FRC) safety
Security anti-theft lock hole (cable lock needs to be purchased separately)Anti-theft base lock slot (use screws to lock the base to the monitor)
follow standards
Energy Star certified monitor.EPEAT registered (if applicable). EPEAT registration standards vary from country to country. For registration status information by country/region, please see https://www.epeat.net.
TCO Certified & TCO Certified Edge.
RoHS compliant.
Monitor does not contain BFR/PVC (excluding external cables).
Meets NFPA 99 leakage regulations.
Panels use only arsenic-free glass and contain no mercury
Flat screen display mounting interface
VESA mounting hole (100 mm x 100 mm, behind attached VESA cover) temperature range
In operation: 0 ° C~40 ° C (32 ° F~104 ° F)Not in operation: -20 ° C~60 ° C (-4 ° F~140 ° F), storage and shipping
Humidity range
During operation: 10%~80% (no condensation) Non-operating: 5%~90% (no condensation), storage and transportation
Altitude
In operation: up to 5,000 m (16,404 ft)Not in operation: up to 12,192 m (40,000 ft)
Voltage requirements
100 VAC~240 VAC/50 Hz or 60 Hz ± 3 Hz/4.2 A (standard value) Power consumption (normal operation)
0.3W (off mode)0.4W (standby mode)
1.8W (networked standby mode)
39.5W (on mode)
380W (maximum)
45W (Pon)
153.6 kWh (TEC)
Cable included
- 1 power cable
- 1 DisplayPort 1.4 cable (1.8 m)
- 1 USB Type-A to USB Type-C Gen 2 cable (1 m)
- 1 HDMI cable (1.8 m)
- 1 Thunderbolt TM 4 active cables (1.5 m)
Package Contents
Monitor Base Stand Base Quick Installation Guide Safety, Environmental and Regulatory Information Original Factory Calibration Report Entity characteristics
Including base height (folded to unfolded)
472.32mm~622.32mm Including base width
946.62mm Depth including base
252.80 mm Does not include base height
419.14 mm Excluding base width
946.62mm Without base depth
108.04 mm Weight (panel only - VESA mount)
8.35kg Weight (including base accessories and cables)
12.22kg Weight (including packaging)
19.02kg Warranty
Specifications: Service/Support Details
3-year Premium Exchange Service and Premium Panel Replacement
