Description
Performance |
||
| NAT Session | 30K | |
| Max. NAT (Mbps) | 530 | |
| Max. NAT with Hardware Acceleration (Mbps) | 930 | |
WAN |
||
| Ethernet (GbE) | 1 | |
| Switchable WAN/LAN (GbE) | 1 | |
| 3G/4G/LTE (via USB) | 1 | |
| Wireless WAN (2.4GHz or 5GHz) | Yes | |
Internet Connection |
||
| IPv4 |
PPPoE
DHCP
Static IP
PPTP/L2TP
|
|
| IPv6 |
PPP
DHCPv6
Static IPv6
TSPC
AICU
6th
6in4 Static Tunnel
|
|
| 802.1p/q Multi-VLAN Tagging | Yes | |
| Multi-VLAN/PVC | Yes | |
| Failover | Yes | |
| Load Balancing | IP-based, Session-based | |
| WAN Active on Demand | Link Failure, Traffic Threshold | |
| Connection Detection | ARP, Ping, Strict ARP | |
| WAN Data Budget | Yes | |
| Dynamic DNS | Yes | |
| DrayDDNS | Yes | |
LAN |
||
| Fixed LAN (RJ-45, GbE) | 3 | |
| LAN Subnet | 4 | |
| VLAN |
802.1q Tag-based VLAN
Port-based VLAN
|
|
| Max. Number of VLAN | 8 | |
| DHCP Server |
Multiple IP Subnet
Custom DHCP Options
Bind-IP-to-MAC
|
|
| Port Mirroring | Yes | |
| Local DNS Server | Yes | |
| Conditional DNS Forwarding | Yes | |
| Hotspot Web Portal (Profile No.) | 2 | |
| Hotspot Authentication |
Click-Through
Social Login
SMS PIN
RADIUS
External Portal Server
|
|
Other Ports |
||
| USB | 1 | |
| USB Type | 2.0 | |
Networking |
||
| Routing |
IPv4 Static Route
IPv6 Static Route
Policy Route
Inter-VLAN Route
RIP v1/v2
|
|
| Policy-based Routing |
Protocol
IP Address
Port
Domain
Country
|
|
| DNS Security (DNSSEC) | Yes | |
| IGMP |
IGMP v2/v3
IGMP Proxy
IGMP Snooping & Fast Leave
|
|
| SMB File Sharing (Requires external storage) | Yes | |
VPN |
||
| LAN-to-LAN | Yes | |
| Teleworker-to-LAN | Yes | |
| Protocols |
PPTP
L2TP
IPsec
L2TP over IPsec
SSL
GRE
IKEv2
IKEv2-EAP
IPsec-XAuth
OpenVPN
|
|
| Max.VPN Tunnels | 16 | |
| Max. OpenVPN + SSL VPN Tunnels | 8 | |
| IPsec VPN Throughput (AES 256 bits) (single-directional) (Mbps) | 250 | |
| SSL VPN Throughput (single-directional) (Mbps) | 150 | |
| User Authentication |
Local
RADIUS
LDAP
mOTP
|
|
| IKE Authentication | Pre-Shared Key, X.509 | |
| IPsec Authentication | MD5, SHA-1, SHA-256 | |
| Encryption |
MPPE
DES
3DES
AES
|
|
| VPN Trunk (Redundancy) | Failover | |
| Single-Armed VPN | Yes | |
| NAT-Traversal (NAT-T) | Yes | |
| VPN Matcher | Yes | |
Firewall & Content Filtering |
||
| NAT |
Port Redirection
Open Ports
Port Triggering
DMZ Host
UPnP
|
|
| ALG (Application Layer Gateway) | FTP, H.323, RTSP, SIP | |
| VPN Pass-Through | IPsec, L2TP, PPTP | |
| IP-based Firewall Policy | Yes | |
| Content Filtering |
APP
URL Keyword
DNS Keyword
Web Features
Web Category*(*subscription required)
|
|
| DoS Attack Defense | Yes | |
| Spoofing Defense | Yes | |
Bandwidth Management |
||
| IP-based Bandwidth Limit | Yes | |
| IP-based Session Limit | Yes | |
| QoS (Quality of Service) |
TOS
DSCP
802.1p
IP Address
Port
Application
|
|
| VoIP Prioritization | Yes | |
| APP QoS | Yes | |
