Description
Performance
WAN
Internet Connection
PPPoE
DHCP
Static IP
IPv6
PPP
DHCPv6
Static IPv6
TSPC
AICU
6th
6in4 Static Tunnel
802.1p/q Multi-VLAN Tagging Multi-VLAN/PVC Failover Load BalancingIP-based, Session-basedWAN Active on DemandLink Failure, Traffic ThresholdConnection DetectionARP, Ping, Strict ARPWAN Data Budget Dynamic DNS DrayDDNS
LAN
802.1q Tag-based VLAN
Port-based VLAN
Max. Number of VLAN100DHCP Server
Multiple IP Subnet
Custom DHCP Options
Bind-IP-to-MAC
LAN IP Alias IP Pool Count4000PPPoE Server Port Mirroring Local DNS Server Conditional DNS Forwarding Hotspot Web Portal (Profile No.)4Hotspot Authentication
Click-Through
Social Login
SMS PIN
RADIUS
External Portal Server
Other Ports
Networking
IPv4 Static Route
IPv6 Static Route
Policy Route
Inter-VLAN Route
Fast Routing
RIP v1/v2
BGP
OSPFv2
Policy-based Routing
Protocol
IP Address
Port
Domain
Country
Smart Action High Availability DNS Security (DNSSEC) IGMP
IGMP v2/v3
IGMP Proxy
IGMP Snooping & Fast Leave
Local RADIUS server
VPN
PPTP
L2TP
IPsec
L2TP over IPsec
SSL
GRE
IKEv2
IPsec-XAuth
OpenVPN(Host to LAN)
Wireguard
Max. VPN Tunnels500Max. OpenVPN + SSL VPN Tunnels200IPsec VPN Throughput (AES 256 bits) (single-directional) (Mbps)3300SSL VPN Throughput (single-directional) (Mbps)3300User Authentication
Local
RADIUS
LDAP
TACACS+
mOTP
TOTP
IKE AuthenticationEAP, Pre-Shared Key, X.509, XAuthIPsec AuthenticationMD5, SHA-1, SHA-256, SHA-512Encryption
MPPE
DES
3DES
AES
VPN Trunk (Redundancy)Failover, Load BalancingSingle-Armed VPN NAT-Traversal (NAT-T) VPN from LAN VPN Isolation VPN Packet Capture VPN 2FA Authentication for AD/LDAP VPN Matcher
Firewall & Content Filtering
Port Redirection
Open Ports
Port Triggering
Port Knocking
Fast NAT
DMZ Host
UPnP
Server Load Balance
ALG (Application Layer Gateway)FTP, H.323, RTSP, SIPVPN Pass-ThroughIPsec, L2TP, PPTPIP-based Firewall Policy Content Filtering
APP
URL Keyword
DNS Keyword
Web Features
Web Category*(*subscription required)
DoS Attack Defense Spoofing Defense
Bandwidth Management
TOS
DSCP
802.1p
IP Address
Service Type
VoIP Prioritization APP QoS
Management
HTTP
HTTPS
Telnet
SSH v2
FTP
TR-069
Config Backup/Restore Firmware UpgradeHTTP, TFTP, TR-0692-Level Administration Privilege Access ControlAccess List, Brute Force ProtectionNotification AlertE-mail, SMSSNMPv1, v2c, v3Syslog AP Managment (APM)50Switch Management (SWM)30VigorACS Management (Since f/w) V4.3.5.1
