Description
Performance |
|
| Buffer Size (Mbit) | 0.096 |
| Switching Capacity (Gbps) | 16 |
| Forwarding Rate (64 bytes)(Mpps) | 11.9 |
| MAC Address Table | 4K |
| Max. Jumbo Frame (KB) | 9 |
Ports |
|
| 1GbE | 8 |
Standard Compliance |
|
| Ethernet Standards |
802.3 10Base-T
802.3u100Base-T
802.3ab 1000Base-T
802.3x Flow Control
802.3 Auto-Negotiation
802.1q Tag-based VLAN
802.1p Class of Service
802.3adLACP
802.3az EEE
|
Link Aggregation |
|
| Max. Number of Group | 1 |
| Max. Number of Member in Each Group | 2 |
| Type | LACP |
VLAN |
|
| Max. Number of VLAN | 8 |
| VLAN Type |
802.1q Tag-based VLAN
|
Multicast |
|
| IGMP Snooping | v2 |
| Max. Number of Multicast Group | 128 |
QoS |
|
| Number of QoS Queues | 4 |
| Queue Schedule | WFQ, WRR |
| CoS (Class of Service) |
CoS
|
| Rate Limiting | |
Security |
|
| Traffic Control | Storm Control |
| Loop Protection | |
Management |
|
| Local Service |
HTTP
|
| Config Backup/Restore | |
| VigorRouter Management (SWM) | |
| VigorConnect Management (Since f/w) | V1.05.0 |
Physical |
|
| Power Input | DC 5V@1A |
| Max. Power Consumption (watts) | 3.3 |
| Dimension(mm) | 154 x 85 x 26 |
| Weight (kg) | 0.32 |
| Operating Temperature | 0 to 45°C |
| Storage Temperature | -20 to 70°C |
| Operating Humidity (non-condensing) | 10 to 90% |
| Storage Humidity (non-condensing) | 5 to 90% |
