Description
Specifications
-
3.5"/2.5" drive mounts2
-
Dedicated 2.5" drive mounts2 trays included, 4 positions total
-
Expansion slots7
-
Front interface1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, 2x USB 2.0, Audio I/O, Power button, Reset button
-
Total fan mounts7x 120 or 4x 140 mm and 2x 120 mm
-
Front fan3x 120 or 2x 140 mm, (1x Dynamic X2 GP-14 included)
-
Top fan2x 120 or 2x 140mm
-
Rear fan1x 120 mm, (1x Dynamic X2 GP-12 included)
-
Bottom fan1x 120 mm (requires removal of HDD cage)
-
Dust filtersTop, 2x front, full length bottom
-
Fixed velcro strapsYes
-
Cable routing grommetsYes
-
Captive thumbscrewsHDD brackets, SSD brackets, PSU brackets
-
Left side panelIndustrial sound-damped steel or Tempered Glass
-
Right side panelIndustrial sound-damped steel
Compatibility
-
Motherboard compatibilityATX/mATX/Mini-ITX
-
Power supply typeATX
-
PSU max length200 mm total (165 mm w/ HDD cage and front fan)
-
GPU max length341 mm (360 mm without front fan)
-
CPU cooler max height169mm
-
Front radiatorUp to 360/280 mm (max 145 mm width)
-
Top radiatorUp to 240mm
-
Rear radiator120 mm
-
Bottom radiator120 mm (requires removal of HDD cage)
-
Cable routing space17-28mm
Dimensions
-
Case dimensions (LxWxH)427 x 210 x 474mm
-
Case dimensions w/o feet/protrusions/screws415 x 210 x 451mm
-
Package dimensions (LxWxH)536 x 310 x 521mm
-
Net weightSolid version: 8.61 kg, TG Version: 8.76 kg
-
Package weightSolid version: 10.87 kg, TG Version: 11.04 kg
-
Volume39.3 liters
Other
-
Warranty2 Years
-
Package contentsDefine 7 Compact, Accessory box, User manual, Ventilated top panel
-
EANBlack Solid - 7340172702160, White Solid - 7340172702764, Black TG Dark Tint - 7340172702177, Black TG Light Tint - 7340172702184, White TG Clear Tint - 7340172702719
-
UPCBlack Solid - 843276102166, White Solid - 843276102760, Black TG Dark Tint - 843276102173, Black TG Light Tint - 843276102180, White TG Clear Tint - 843276102715
-
JANBlack Solid - 4537694275712, White Solid - 4537694280839, Black TG Dark Tint - 4537694275729, Black TG Light Tint - 4537694275736, White TG Clear Tint - 4537694280822
-
Product codeBlack Solid - FD-C-DEF7C-01, White Solid - FD-C-DEF7C-05, Black TG Dark Tint - FD-C-DEF7C-02, Black TG Light Tint - FD-C-DEF7C-03, White TG Clear Tint-FD-C-DEF7C-04
