Description
FSP Hydro PTM PRO 1650W
- More than 92% high efficiency conversion rate
- Passes 80 Plus® Platinum Certification Standard
- Comply with the latest ATX12 v2.52 standard
- ECO fan temperature control switch switching design
- Industrial grade unique moisture-proof coating technology
- Japanese industrial grade electrolytic capacitors
- The world's original replaceable side label sticker
- +12V single-channel power output design
- Long-lasting and quiet 135mm FDB liquid bearing fan
- Multiple protection mechanisms: OCP, OVP, SCP, OPP, OTP, UVP
- Comply with national safety regulations and certifications
Industrial grade unique moisture-proof coating technology
Moisture-proof, dust-proof and rust-proof
Leading the retail power supply industry, the circuit board adopts the industrial-grade power supply's "unique moisture-proof coating" process, which emphasizes moisture-proof, dust-proof, and rust-proof, ensuring excellent and stable electrical performance in harsh environments, and providing users with a safe and secure experience. .
King layout LLC full-bridge resonant structure DC-DC synchronous rectification design
The LLC full-bridge resonant structure ensures the output voltage from low load to high load, maintains the minimum electrical frequency jump, and cooperates with the DC-DC synchronous rectification design to adjust the voltage so that the output voltage variation rate is within plus or minus 1%, providing computer zero The highly stable and compatible power supply of the components demonstrates the excellent performance of the system operation.
Module black flat wire design
You can plan the wires to be installed by yourself. The black flat wire is easy to bend and easy to install. The wiring inside the machine is clean and ventilated, providing users with a free, labor-saving and beautiful solution for assembly.
Temperature control switch silent heat dissipation
Users can switch the "Eco" fan switch by themselves. When started, the fan will not rotate when the load is below 30%, providing users with a quiet environment.
Intelligent temperature control circuit design, combined with a 135mm fluid bearing fan (FDB), maintains low-noise performance under high-load operation, making it feel like you are in a silent night.
92% high-efficiency conversion significantly reduces waste heat generated by components, while also extending service life and power performance, saving the earth's energy and your wallet.
Ten years warranty
The entire series comes with a ten-year warranty, and the circuit design, component materials and manufacturing processes can stand the test of time.
Comply with the latest international safety regulations
As one of the world's leading international power supply manufacturers, FSP, together with international safety organizations, promises and practices to protect the safety of users. The HYDRO PTM PRO series complies with the latest international safety regulations IEC/EN 62368. The air holes are designed to be smaller to prevent the intrusion of foreign objects, and the protection level is comprehensively improved to protect user safety.
Circuit design that keeps pace with the times
Corresponds to the latest CPU platform. Comply with Intel ATX12V V2.52 power supply design guideline to ensure the maximum output power of 12V supports the latest Intel/AMD platform and provides full power for your PC system.
360-degree circuit protection design
The six-layer protection mechanism of OCP, OVP, SCP, OPP, UVP, and OTP provides players and equipment with more secure and comprehensive security protection.
 |
 |
 |
 |
 |
 |
|
| ATX 20+4 | 4+4PIN | PCI-E 6+2 | SATA | Molex (PERIPHERAL) |
Floppy | |
| Connectors | 1 | 2 | 4 | 12 | 3 | 1 |
AC/DC
| AC Input | 100-240Vac~ 10-5A 50-60Hz | ||||
| DC Output | +3.3V | +5V | +12V | -12V | +5Vsb |
| Max Output Current | 20A | 20A | 54.17A | 0.3A | 3A |
| Max Combined Power | 120W | 650W | 18.6W | ||
| Total Power | 650W | ||||
Specification
| Product number | HPT2-1650M |
|---|---|
| rated power | 1650W |
| Form Factor | ATX |
| 80 PLUS level | Platinum |
| Input voltage | 100-240V |
| Input Current | 10-5A |
| Input voltage frequency | 50-60Hz |
| Power corrected PFC | Active PFC |
| Conversion efficiency | ≥92% at typical load |
| fan | FDB Fan, 135mm |
| Dimensions (length x width x height) | 150x170x86mm |
| operating temperature | 0-50℃ |
| protection mechanism | OCP, OVP, SCP, OPP, OTP, UVP |
| Packaging information | 2.584kg / 324L*253W*101H mm |
| Barcode | EAN:471322452275 8 UPC:84568501068 1 |
| BSMI | CI438060016412 No. 00 |
