Description
CPU Specifications
Total Cores
10
# of Performance-cores
6
# of Efficient-cores
4
Total Threads
16
Max Turbo Frequency
4.90GHz
Performance-core Max Turbo Frequency
4.90GHz
Efficient-core Max Turbo Frequency
3.60 GHz
Performance-core Base Frequency
3.70GHz
Efficient-core Base Frequency
2.80GHz
Cache
20MB Intel® Smart Cache
Total L2 Cache
9.5 MB
Processor Base Power
125W
Maximum Turbo Power
150W
Supplemental Information
Marketing Status
Launched
Launch Date
Q4'21
Embedded Options Available
No
Datasheet
Memory Specifications
Max Memory Size (dependent on memory type)
128GB
Memory Types
Up to DDR5 4800MT/s
Up to DDR4 3200MT/s
Up to DDR4 3200MT/s
Max # of Memory Channels
2
Max Memory Bandwidth
76.8GB/s
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations ‡
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes
20
Package Specifications
SocketsSupported
FCLGA1700
Max CPU Configuration
1
Thermal Solution Specification
PCG 2020A
T JUNCTION
100°C
Package Size
45.0 mm x 37.5 mm
Max Operating Temperature
100°C
Advanced Technologies
Intel® Gaussian & Neural Accelerator
3.0
Intel® Thread Director
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Optane™ Memory Supported ‡
Yes
Intel® Speed Shift Technology
Yes
Intel® Turbo Boost Max Technology 3.0 ‡
No
Intel® Turbo Boost Technology ‡
2.0
Intel® Hyper-Threading Technology ‡
Yes
Intel® 64 ‡
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Intel® Volume Management Device (VMD)
Yes
Security & Reliability
Intel® Standard Manageability (ISM) ‡
Yes
Intel® Control-Flow Enforcement Technology
Yes
Intel® AES New Instructions
Yes
Secure Key
Yes
Intel® OS Guard
Yes
Execute Disable Bit ‡
Yes
Intel® Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel® Virtualization Technology (VT-x) ‡
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes
Intel® VT-x with Extended Page Tables (EPT) ‡
Yes
