Description
| physical dimension | M.2 2280 |
| interface | PCIe 4.0 x4 NVMe |
| Storage capacity 2 | 1024GB |
| controller | Phison E18 |
| NAND | 3D TLC |
| Continuous read/write | 1024GB – 7,000/6,000MB/s |
| Max 4K read/write 1 | 1024GB – up to 900,000/1,000,000 IOPS |
| Total number of bytes of data written (TBW) 3 | 1024GB – 800TBW |
| Power consumption |
1024GB – 50mW idle / 0.33W average / 2.8W (max) read / 6.3W (max) write |
| Storage temperature | -40°C~85°C |
| Operating temperature | 0°C~70°C |
| size | 80mm x 22mm x 2.21mm (512GB-1024GB) |
| weight | 512GB-1024GB – 7g |
| Operation vibration peak value | 2.17G (7-800Hz) |
| Non-operating vibration peak value | 20G (20-1000Hz) |
| Mean time between failures (MTBF) | 2,000,000 hours |
| Warranty/Technical Support4 | Limited 5-year warranty, free technical support |
