Description
Intel® Core™ i9-14900HX CPU
Intel® UHD Graphics
Dual channel DDR5 memory (up to 64GB)
1 x HDMI, 1 x DisplayPort, 1 x USB Type-C Ports
4 x PCIe 4.0 M.2 Slots, 1 x PCIe 5.0 x16 expansion slot
Support high-end AMD / Nvidia graphics cards
USB 3.2, USB 2.0 ports, 2.5GbLAN, WiFI card
mini-ITX
product description
The motherboard is pre-installed with the " Intel® Core™ i9-14900HX " processor. You need to purchase the memory and SSD yourself.
| CPU | Intel® Core™ i9-14900HX Processor, 24 Cores/32 Threads (36M Cache, up to 5.8 GHz) |
| GPU | Intel® UHD Graphics for 14th Gen Intel® Processors |
| chipset | Intel® HM770 Chipset |
| Memory | DDR5 Dual channel (SODIMM Slots×2, up to 5600 MT/s, Max 64GB) |
| storage | 4×M.2 2280 PCIe4.0 SSD Slots |
| storage expansion | PCIe 5.0 X16 connector ×1 |
| Wireless connections | M.2 2230 Key E Slot |
| Video output | HDMI2.0 ×1; DisplayPort1.4 ×1; USB-C ×1 |
| Audio output | HDMI2.0 ×1; DisplayPort1.4 ×1; USB-C ×1; Line Out ×1 |
| Ethernet | RJ45 2.5G Ethernet Port×1 |
| USB interface | USB3.2 Gen2 Type-C Port ×1(Alt DP) USB3.2 Gen2 Type-A Port ×2 USB2.0 Type-A Port ×2 |
| I/O interface | 4-pin CPU Fan header ×1 4-pin System Fan header ×2 4-pin SSD Fan header ×1 USB 3.2 Gen 1 header ×1 Front Panel Audio header ×1 System Panel header ×1 |
| Specification | Mini-ITX Form Factor(170x170mm) |
