Description
| model | MDSA156 | |
| screen size | Double 15.6" | |
| resolution | Double 1920*1080 | |
| Proportion | 16:9 | |
| panel | IPS | |
| Panel surface | anti-glare | |
| Viewing angle (H/V) |
178° / 178° | |
| brightness | 250 cd/m² (typ) | |
| Contrast | 1000:1 (typ) | |
| color depth | Up to 10 BPC | |
| Color gamut | 45%NTSC | |
| reaction time | 20ms (rising + falling) |
|
| refresh rate | 60 Hz | |
| interface | 2*USB-C, HDMI, 3.5audio |
|
| Built-in speaker | support | |
|
Rated power
|
Power on | ≤30W |
| standby | ≤ 0.5 W | |
| Shut down | ≤ 0.5 W | |
| power supply | PD: 9V 3A; 12V 2.5A; 15V 2A; 20V 1.5A |
|
|
indicator orange
|
Power on | Green (LED) |
| Guan Guan | Red(LED) | |
| temperature | 0°C - 40°C | |
| humidity | RH 20% - RH 85% | |
|
adjust
|
Bracket | 0° - 135° |
| screen | 0° - 315° | |
|
feet
|
product | 355.7*217.3*22.3mm |
| Package | 398*260*61mm | |
|
weight
|
net weight | 1.46kg |
| gross weight | 2.4kg | |
