Description
MEG CORELIQUID S series silent water cooling, equipped with the exclusive MEG SILENT GALE P12 silent fan, provides intelligent stop mode function. The 2.4-inch IPS screen can also display the hardware information you need and customize your favorite pictures, videos, etc. When facing the MEG CORELIQUID S series silent water cooling, you will find that it really works quietly for you.
NEXT-GEN AMD SOCKET AM5 SUPPORT
Silent cooling
MSI's MEG SILENT GALE P12 fan provides sufficient airflow for water cooling while maintaining low noise.
MEG SILENT GALE P12
MSI's MEG SILENT GALE P12 fan provides sufficient airflow for water cooling while maintaining low noise.
Focus on cooling performance
The water block has a built-in 6cm fan, which can help quickly discharge the heat generated by M.2 SSD and CPU power supply modules.
0 RPM smart stall mode
MEG SILENT GALE P12 silent fan and water cooling support 0% RPM fan speed, making it quiet in low temperature environments.
2.4” customized IPS display
The MEG CORELIQUID S series is equipped with a 2.4-inch IPS display, which can display a variety of images, including hardware system information, GIF, MP4, text and real-time weather.
- Hardware Monitor
- Video/Image
- System Clock
- Live Weather
It's up to me
MEG CORELIQUID S series fan speed, IPS display and everything can be adjusted and controlled in MSI Center.
Compatible with LGA 1700 pins
MEG CORELIQUID S series integrated water cooling supports LGA 1700 pin processor.
Anti-evaporation water cooling tube design
The MEG CORELIQUID S series adopts a three-layer mesh plastic water cooling pipe design and strengthens the external mesh structure to effectively avoid water leakage problems caused by bending of water pipes.
Specification
| Fan information | |
|---|---|
| Number of fans | 3 |
| fan size | 120 x 120 x 25mm / 4.7 x 4.7 x 0.98 inches |
| speed of the fan | 0~2000RPM |
| Fan light effect | NA |
| Fan air volume | 56.2 CFM |
| fan noise decibels | 22.7 dBA |
| Fan pressure | 2.21mm-H2O |
| fan bearing | Hydro-Dynamic Bearing (HDB) |
| Fan service life | 50,000 hours, 40oC |
| fan current | 0.4 A(Max) |
| Fan power consumption | 4.8 W (Max) |
| PWM mode | Yes |
| Wire length (PWM cable) | 350mm; 13.78 inches |
| ARGB cable connector | NA |
| Water cooling radiator information | |
|---|---|
| Water cooling radiator material | Aluminum |
| Water cooling radiator size (W x D x H) | 394 x 120 x 27mm / 15.5 x 4.7 x 1.06 inches |
| Base material | Copper |
| Water cooling pipe material | Black Rubber + Mesh |
| Water cooling pipe length | 400mm / 15.75 inches |
| Pump/water block information | |
|---|---|
| Water block size (W x D x H) | 95x95x54mm |
| screen size | 2.4” |
| Screen specifications | IPS |
| Screen resolution | 320 x 240 |
| Screen color depth | 16 bits |
| Color depth brightness | 500nits |
| Pump service life | 50,000 hours |
| Pump noise decibels | 21.2 dBA |
| Pump load current | 0.33 A |
| Pump power consumption | 4W |
| Pump speed | PWM controlled; 100% duty cycle w/ 2800 +/-300 RPM |
| SATA power cord | 650mm x 1 |
| USB 2.0 cable | 750mm x 1 |
| Water cooling exhaust fan wire | 400mm x 1 |
| Pump/CPU fan cable | 400mm x 1 |
| Foot position information | |
|---|---|
| Intel pin position | LGA 1150/1151/1155/1156/1200/1700 LGA 2011/2011-3/2066 |
| AMD pin position | AM5/AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2 SocketTR4/sTRX4/SP3 |
