Description
FAN Specification
Size
140x140x25mm
Mounting hole spacing
124,5x124,5mm
4-pin PWM
Cable length
40cm
Bearing
Blade geometry
A-Series with Flow Acceleration Channels
Frame technology
Material
Fibre-glass reinforced polyamide
Ingress protection
IP52
Motor type
Rotational speed (+/- 10%)
3000RPM
Min. rotational speed @ 20% PWM (+/-20%)
800RPM
Acoustical noise
41,3 dB(A)
Static pressure
6,58 mm H₂O
Input power (typical)
6,6W
Input power (max.)
7,26W
Input current (typical)
0,55 A
Max. input current
0,61A
Operating voltage
12 V
MTTF
> 150.000 hours
Scope of delivery
- Fan
- 4 Fan Screws
6 years
