Description
Cooler Specification:
Intel LGA1700 (included since Q3 2021 , older coolers require NM-i17xx-MP83 ), LGA1200 , LGA1156, LGA1155, LGA1151, LGA1150, LGA2066 , LGA2011-0 & LGA2011-3 ( Square ILM ) & AMD AM4, AM5 (included since 2019 , older coolers require NM-AM4 )
Height (without fan)
115mm
Width (without fan)
140mm
Depth (without fan)
163mm
Height (with fan)
115/142 mm
Width (with fan)
140mm
Depth (with fan)
163mm
Weight (with fan)
1015g
Material
Copper (base and heat-pipes), aluminum (cooling fins), soldered joints & nickel plating
119
Max.TDP
see NSPR
Fan compatibility
Scope of delivery
- 1x NF-A14 PWM premium fan
- Low-Noise Adapter (LNA)
- Fan clips for second fan
- NT-H1 high-grade thermal compound
- SecuFirm2™ Mounting Kit
- Noctua Metal Case-Badge
6 Years
FAN Specification
Model
Bearing
Max. rotational speed (+/- 10%)
1500RPM
Max. rotational speed with LNA (+/- 10%)
1200RPM
Min. rotational speed @ 20% PWM (+/-20%)
300 rpm
140,2 m³/h
115,5 m³/h
Max.acoustic noise
24,6 dB(A)
Max. acoustical noise with LNA
19,2 dB(A)
Input power (max.)
1,56 W
Voltage range
12V
MTTF
> 150.000 hours
