Description
CPU | Intel® Celeron® J6412 Quad-core/4-thread processor, overclockable up to 2.6 GHz |
CPU architecture | 64-bit x86 |
graphics processor | Intel® UHD Graphics |
floating point arithmetic | |
encryption engine | (AES-NI) |
Hardware accelerated conversion | |
system memory | 8GB RAM |
Maximum memory | 8GB |
flash memory | 4 GB (dual-boot operating system protection) |
Number of hard drive slots | 2 x 3.5-inch SATA 6Gb/s
The system is shipped without a hard drive.
For a list of hard drive compatibility, please visit https://www.qnap.com/compatibility/ The system is shipped without a hard drive. For a list of hard drive compatibility, please visit https://www.qnap.com/compatibility/ |
Supported hard drive types | 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
Hot plug support | |
M.2 slot | 2 x M.2 2280 PCIe Gen 3 x2
Compatible with NVMe SSDs above PCIe Gen 3. Please check the compatibility list https://www.qnap.com/compatibility/ .
|
SSD cache acceleration support | |
2.5 Gigabit Ethernet port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
Wake on LAN (WOL) | |
jumbo frame | |
USB 2.0 port | 2 |
USB 3.2 Gen 2 (10Gbps) port | 2 x Type-A |
HDMI™ output | 2 x HDMI™ 1.4b (up to 3840 x 2160 @ 30Hz) |
Appearance | upright |
LED indicator | Power/Status, Network, USB, HDD 1-2 |
button | Power, system reset, USB automatic backup |
Dimensions (depth x width x height) | 165 × 102 × 220.6mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
Weight (net weight) | 2.57kg |
Weight (total weight) | 2.57kg |
operating temperature | 0 - 40 °C (32°F - 104°F) |
Storage temperature | -20 - 70 °C (-4°F - 158°F) |
Relative humidity | 5-95% RH (non-condensing), wet bulb: 27˚C (80.6˚F) |
Power Supplier | 60W/65W transformer, 100-240V |
Power consumption: hard disk sleep mode | 20.943 W |
Power consumption: operating mode, normal | 24.238W |
fan | 1 x 70mm, 12VDC |
System alert | buzzer |
Kensington security slot | |
Standard warranty | 3 |
Maximum number of simultaneous connections (CIFS) - maximum memory | 1500 |
