SAMSUNG
Price:
HK$1,299.00

Description

Top 3 features

With the 9100 PRO it says "up to 2x faster" and "PCIe® 5.0".

PCIe® 5.0 Performance

Max 14,800/13,400 MB/s sequential speeds, two times faster than 990 PRO.
Various game screens are shown centered around the 9100 PRO, and it says "8TB".

Expanded Experience

Supermassive capacity with exceptional compatibility.

* Availability may vary depending on market and timing.
The detailed components that make up the 9100 PRO are visible. There are two components that say "SAMSUNG V-NAND" and one component each that says "SAMSUNG DRAM" and "SAMSUNG Controller." Around it, an arrow indicating the direction in which heat is emitted is visible.

Innovative Power &
Thermal Control

Up to 49% enhanced power efficiency with advanced thermal control.



Breakthrough PCIe® 5.0 performance

Push PCIe® 5.0 performance to the max. 9100 PRO achieves lightning-fast sequential read/write speeds up to 14,800/13,400 MB/s, two times faster than 990 PRO. Leave Gen4 limits behind with random read/write speeds up to 2,200K/2,600K IOPS, only possible by Gen5.


With the 9100 PRO, it says "up to 2x faster", "PCIe® 5.0". Below that, it says "Sequential Read up to 14,800 MB/s", "Sequential Write up to 13,400 MB/s" with icons indicating Sequential speed, and "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" with icons indicating Random speed.
* Sequential and random performance was measured with Intelligent Turbo Write technology activated, which only operates within a specific data transfer size.
Performance may vary depending on SSD’s firmware, system hardware & configuration and other factors. For detailed information, please contact your local service center.
* To maximize the performance of the 9100 PRO, please check whether your system supports PCIe® 5.0 on Intel or AMD website.


Every task, powerfully parallel

Speed past productivity limits. Exhilarating random read/write speeds enable ultra-fast parallel processing for countless fragmented data, at up to 2,200K/2,600K IOPS. Experience superior output and instant loads for huge games, high-performance tasks, and even AI applications.


Several puzzle pieces are coming together. It says "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" along with an icon indicating Random speed.


Create with AI in an instant

Intelligence redefines performance. Defy your limits in work and play with an on-board AI PC and AI content generation, fuelled by 9100 PRO’s exhilarating random read/write speeds up to 2,200K/2,600K IOPS. Swift loads, smooth gameplay, seamless performance.


A person is using an AI application on a laptop. It has the words "Random Read up to 2,200K IOPS" and "Random Write up to 2,600K IOPS" written on it, along with an icon indicating random speed.
* Performance may vary depending on SSD's firmware, system hardware & configuration and other factors.


Exceptional everywhere

Elevate your competitive edge. Breeze through video editing, 3D art, and even long streaming sessions with the latest PCIe® 5.0 interfaces. Experience cutting-edge performance anytime, anywhere, on any device, and choose the storage you need with expansive capacity up to 8TB.


Several cases of using desktop PC, laptop. Below, there are icons written by 1TB, 2TB, 4TB, and 8TB.
* Availability may vary depending on market and timing.


Extraordinary thermal efficiency

Peak performance, uninterrupted. The advanced 5nm controller power architecture enhances power efficiency up to 49% over 990 PRO. Exceptional thermal control ensures nothing disrupts your flow, so you can keep the most demanding programs running with the max possible power of PCIe® 5.0.


The detailed components that make up the 9100 PRO are visible. There are two components that say "SAMSUNG V-NAND" and one each that says "SAMSUNG DRAM" and "SAMSUNG Controller." Around it, an arrow indicating the direction in which heat is emitted is visible, and "Nickel coated controller" and "Heat spreader label" are written. On one side again, "Thermal Control" is written with the icon, which means temperature control.
* Image shown for illustrative purposes only.

* 990 PRO sequential read/write 1,221/1,255 MB/s per Watt, 9100 PRO sequential read/write 1,822/1,703 MB/s per Watt based on the internal test result of the 2TB capacity model.

Samsung Magician software

Make your SSD work like magic. Samsung Magician software's optimization tools ensure the best SSD performance. It's a safe and easy way to migrate all your data for a Samsung SSD upgrade. Protect valuable data, monitor drive health, and get the latest firmware updates.


* For detailed information, please visit Samsung Magician software website.
https://semiconductor.samsung.com/consumer-storage/magician/
The detailed components that make up the 9100 PRO are visible. There are two components that say "SAMSUNG V-NAND" and one each that says "SAMSUNG DRAM" and "SAMSUNG Controller." Around it, an arrow indicating the direction in which heat is emitted is visible, and "Nickel coated controller" and "Heat spreader label" are written. On one side again, "Thermal Control" is written with the icon, which means temperature control.

Bringing innovations to life

For decades, Samsung’s NAND flash memory has powered groundbreaking technologies that have changed every part of our daily lives. This NAND flash technology also powers our consumer SSDs, making room for the next big push of innovation.



Samsung's memory products are installed on the motherboard.

Specifications

  • Form Factor
    M.2
  • Capacity
     4TB
  • Sequential Read Speed
    Up to 14,800 MB/s
  • Sequential Write Speed
    Up to 13,400 MB/s

General Feature

  • Application

    Client PCs, PlayStation®5

  • FORM FACTOR

    M.2 (2280)

  • INTERFACE

    PCIe® 5.0 x4, NVMe™ 2.0

  • DIMENSION (WxHxD)

    1TB/2TB/4TB : 80.15 x 22.15 x 2.38 mm
    8TB : 80.15 x 22.15 x 3.88 mm

  • STORAGE MEMORY

    Samsung V-NAND TLC

  • CONTROLLER

    Samsung in-house Controller

  • CACHE MEMORY

    Samsung 1GB Low Power DDR4X SDRAM (1TB)
    Samsung 2GB Low Power DDR4X SDRAM (2TB)
    Samsung 4GB Low Power DDR4X SDRAM (4TB)
    Samsung 8GB Low Power DDR4X SDRAM (8TB)

Special Feature

  • TRIM Support

    Supported

  • S.M.A.R.T Support

    Supported

  • GC (GARBAGE COLLECTION)

    Auto Garbage Collection Algorithm

  • ENCRYPTION SUPPORT

    AES 256-bit Encryption (Class 0) TCG/Opal
    IEEE1667 (Encrypted drive)

  • WWN SUPPORT

    Not supported

  • DEVICE SLEEP MODE SUPPORT

    Yes

Performance2)

  • SEQUENTIAL READ

    1TB: Up to 14,700 MB/s
    2TB: Up to 14,700 MB/s
    4TB: Up to 14,800 MB/s
    8TB: Up to 14,800 MB/s (TBD)

  • SEQUENTIAL WRITE

    1TB: Up to 13,300 MB/s
    2TB: Up to 13,400 MB/s
    4TB: Up to 13,400 MB/s
    8TB: Up to 13,400 MB/s (TBD)

  • RANDOM READ (4KB, QD32)

    1TB: Up to 1,850,000 IOPS
    2TB: Up to 1,850,000 IOPS
    4TB: Up to 2,200,000 IOPS
    8TB: Up to 2,200,000 IOPS (TBD)

  • RANDOM WRITE (4KB, QD32)

    1TB: Up to 2,600,000 IOPS
    2TB: Up to 2,600,000 IOPS
    4TB: Up to 2,600,000 IOPS
    8TB: Up to 2,600,000 IOPS (TBD)

Environment

  • AVERAGE POWER CONSUMPTION
    (System Level)3)

    1TB: Average 7.6 W Maximum 7.2 W (Burst mode)
    2TB: Average 8.1 W Maximum 7.9 W (Burst mode)
    4TB: Average 9 W Maximum 8.2 W (Burst mode)

  • POWER CONSUMPTION (IDLE)3)

    1TB: Max. 4 mW
    2TB: Max. 4.8 mW
    4TB: Max. 6.5 mW

  • POWER CONSUMPTION (DEVICE SLEEP)

    1TB: Max. 3.3 mW
    2TB: Max. 4 mW
    4TB: Max. 5.7 mW

  • ALLOWABLE VOLTAGE

    3.3 V ± 5 % Allowable voltage

  • RELIABILITY (MTBF)

    1.5 Million Hours Reliability (MTBF)

  • OPERATING TEMPERATURE

    0 - 70 ℃ Operating Temperature

  • Shock

    1,500 G & 0.5 ms (Half sine)

Software

Warranty4)

  • MZ-VAP1T0BW (1TB)

    5-year or 600 TBW limited warranty

  • MZ-VAP2T0BW (2TB)

    5-year or 1200 TBW limited warranty

  • MZ-VAP4T0BW (4TB)

    5-year or 2400 TBW limited warranty

  • MZ-VAP8T0BW (8TB)

    5-year or 4800 TBW limited warranty
