Description
|
Technical specifications |
||
|---|---|---|
|
80PLUS® |
Gold |
|
|
Cybenetics efficiency levels |
Gold |
|
|
Cybenetics Noise Level |
one- |
|
|
Power supply size |
ATX/EPS |
|
|
Fan information |
fan size |
135mm |
|
Fan temperature control |
Haiyun HYBRID SILENT FAN CONTROL silent design |
|
|
fan bearing |
Hydrodynamic Bearings |
|
|
life expectancy |
50,000 hours at 40 °C, 15% - 65% RH |
|
|
Wire information |
Wire configuration |
Fully modular wire |
|
Wire type |
Personal black wire with braided pattern |
|
|
Electrical characteristics |
working temperature |
0 - 50°C |
|
MTBF @ 25 °C, excluding fan |
100,000 hours |
|
|
AC input |
All-round |
|
|
Protect |
OCP, OPP, OTP, OVP, SCP, UVP |
|
|
safety and environment |
Safety and EMC |
CB, CCC, CE, cTUVus, EAC, TUV, BSMI, FCC |
|
environmental compliance |
Energy Star, ErP Lot 6, REACH, RoHS, WEEE |
|
|
Product warranty |
10 years |
|
|
Power output |
||||||
|---|---|---|---|---|---|---|
|
AC input |
100 volts - 240 volts |
|||||
|
13 - 6.5 amps |
||||||
|
50 Hz - 60 Hz |
||||||
|
DC output |
rail |
+3.3 V |
+5 V |
+12 V |
-12 V |
+5 VSB |
|
Maximum power |
25A |
25A |
83A |
0.3 A |
3A |
|
|
125W |
996W |
3.6 W |
15W |
|||
|
total continuous power |
1000W |
|||||
