Description
| Technical specifications | ||
|---|---|---|
| 80PLUS® | Gold | |
| Cybenetics efficiency levels | To be determined | |
| Cybenetics Noise Level | To be determined | |
| Power supply size | ATX/EPS | |
| Fan information | fan size | 135mm |
| Fan temperature control | Haiyun HYBRID SILENT FAN CONTROL silent design | |
| fan bearing | Hydrodynamic bearings | |
| life expectancy | 50,000 hours at 40 °C, 15% - 65% RH | |
| Wire information | Wire configuration | Fully modular wire |
| Wire type | Personal white wire with braided pattern | |
| Electrical characteristics | working temperature | 0 - 50°C |
| MTBF @ 25 °C, excluding fan | 100,000 hours | |
| AC input | All-round | |
| Protect | OCP, OPP, OTP, OVP, SCP, UVP | |
| safety and environment | Safety and EMC | BSMI, CB, CCC, CE, cTUVus, EAC, FCC, TUV |
| environmental compliance | Energy Star, ErP Lot 6, REACH, RoHS, WEEE | |
| Product warranty | 10 years | |
| Power output | ||||||
|---|---|---|---|---|---|---|
| AC input | 100 volts - 240 volts | |||||
| 10 - 5 amps | ||||||
| 50 Hz - 60 Hz | ||||||
| DC output | rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum power | 20A | 20A | 62A | 0.3 A | 3A | |
| 100W | 744W | 3.6 W | 15W | |||
| total continuous power | 750W | |||||
