Description
Versatile AI cameras for securing any location:
- Consistent clear footage 24/7
- Enhance your surveillance with camera-based AI
- Effortless setup and access from anywhere
- Safety and security you can rely on
- 5 MP & 110° wide field of view
- IP67 & IK101 certified
- 30 m night vision: See clearly at night with four high-power IR LEDs that provide 30 meters of night vision range.
- NDAA & TAA compliant
People and Vehicle Detection
Protect against loitering and boost security with cameras that leverage AI to distinguish people and vehicles from other moving objects with high accuracy.
Intrusion Detection
Identify trespassers without maintaining dedicated staff on site. Draw virtual borders to automatically receive alerts when people or vehicles cross.
Instant Search
Investigate incidents quickly after they happen. Instant Search lets operators search for activities of interest within a certain area.
Optimized for Surveillance Station
BC500 and TC500 are designed to work in perfect harmony with Surveillance Station.
Streamlined setup and configuration. Simply connect and go. All camera settings, including image quality and network configuration, can be modified directly in Surveillance Station.
Stay in the know with DS cam. DS cam is the powerful companion mobile app for Surveillance Station, available for free on iOS and Android.
|
Hardware Specifications
|
TC500
|
BC500
|
|
|---|---|---|---|
| Optical | Image Sensor | 1/2.7" | 1/2.7" |
| IR LED wavelength | 850 nm | 850 nm | |
| Max. IR distance | 30m (98.4ft) (0.001lux) | 30m (98.4ft) (0.001lux) | |
| Shutter Speed | 1/16000 s to 1/30 s | 1/16000 s to 1/30 s | |
| Day & Night | Automatically removable infrared-cut filter | Automatically removable infrared-cut filter | |
| Lens | Lens type | Fixed Focal | Fixed Focal |
| Focal Length | 2.8 mm | 2.8 mm | |
| Field of View | 110° H, 56° V, 132° D (LDC ON) |
110° H, 56° V, 132° D (LDC ON) |
|
| DORI | D: 60m, O: 24m, R: 12m, I: 6m | D: 60m, O: 24m, R: 12m, I: 6m | |
| Aperture | F1.8 | F1.8 | |
| Video | Max. video resolution | 2880x1620 @ 30 FPS | 2880x1620 @ 30 FPS |
| Multi-exposure HDR | |||
| DNR |
|
|
|
| Audio | Microphone | ||
| I/O | Ethernet | RJ45 10M/100M Ethernet port X 1 | RJ45 10M/100M Ethernet port X 1 |
| Reset | |||
| On-Board Storage | MicroSD card slot X 1 Support microSD card up to 256GB Supported file format: exFAT Note: microSD card is not included |
MicroSD card slot X 1 Support microSD card up to 256GB Supported file format: exFAT Note: microSD card is not included |
|
| Power Supply | IEEE 802.3af Type 1 Class 3 or 12V DC | IEEE 802.3af Type 1 Class 3 or 12V DC | |
| Note |
|
|
|
| General | Form Factor | Turret | Bullet |
| Dimension | Ø97 × 88 mm (Ø3.82 x 3.46”) | Ø110 × 161 mm (Ø4.33 × 6.34”) | |
| Weight | 387 g (0.85 lbs) | 353 g (0.78 lbs) | |
| Temperature | Operating Condition | Starting temperature:-30°C to 50°C (-22°F to 122°F) Operating temperature:-30°C to 50°C (-22°F to 122°F) (IR off) Operating temperature:-30°C to 40 °C (-22°F to 104°F) (IR on) Operating humidity:5%~95% (non-condensing) |
Starting temperature:-30°C to 50°C (-22°F to 122°F) Operating temperature:-30°C to 50°C (-22°F to 122°F) (IR off) Operating temperature:-30°C to 40 °C (-22°F to 104°F) (IR on) Operating humidity:5%~95% (non-condensing) |
| Storage Condition | Storage temperature:-40°C to 60°C (-40°F to 140°F) Storage humidity:5%~95% (non-condensing) |
Storage temperature:-40°C to 60°C (-40°F to 140°F) Storage humidity:5%~95% (non-condensing) |
|
| Certification |
|
|
|
| Environment |
|
|
|
| Waterproof | IP67 | IP67 | |
| Vandal | IK10 | - | |
| NDAA Compliant | |||
| TAA Compliant | |||
| Warranty | 3-year | 3-year | |
| Packaging Content |
|
|
|
