Description
| P/N | CA-1Y7-00M1WN-00 |
|---|---|
| Series | View |
| Model | View 270 TG ARGB |
| Dimension (H x W x D) | 456 x 230 x 454 mm (18 x 9.1 x 17.9 inches) |
| NET WEIGHT | 6.3 kg / 13.9 lbs. |
| PANEL | Tempered Glass x 2 |
| Color | Black |
| MATERIAL | SPCC |
| COOLING SYSTEM | Rear(exhaust): 140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1 |
| Drive Bays | 2 x 3.5”, 1 x 2.5” or 2 x 2.5” |
| EXPANSION SLOTS | 7 |
| MOTHERBOARDS | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13” (E-ATX) |
| I/O Port | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Top: 3 x 120mm, 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Right (M/B Side): 2 x 120mm, 1 x 120mm Rear: 1 x 120mm, 1 x 140mm Power Cover: 3 x 120mm, 2 x 120mm, 1 x 120mm |
| RADIATOR SUPPORT | Top: 1 x 360mm, 1 x 240mm, 1 x 120mm Rear: 1x120mm |
| CLEARANCE | CPU cooler max height: 180mm VGA max length: 420mm PSU max length: 220mm |
