Description
Features
- AX3000 Dual Band WiFi - Superfast WiFi 6 with speeds up to 3.0 Gbps
- 4 streams, less latency - 2×2/HE160 2402 Mbps + 2×2 574 Mbps
- Gigabit wired speeds - 3 x Gigabit ports provide ample connectivity
- Enhanced Seamless Coverage - Seamless mesh WiFi coverage up to 2500 sq. ft. (1 pack)
- Artificial Intelligence Powered Grid - Intelligently learns the network environment to provide ideal WiFi for your home
- TP-Link HomeShield - provides comprehensive network protection, powerful parental controls and real-time IoT protection
- Setup is easier than ever - the Deco app guides you through it step-by-step
Product introduction
Product Specifications
| wireless network | |
|---|---|
| standard |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
| Wi-Fi speed |
AX3000 5 GHz: 2402 Mbps (802.11ax, HE160) 2.4 GHz: 574 Mbps (802.11ax) |
| Wi-Fi range |
4-6+ Bedroom Houses (3-pack) TP-Link Mesh Technology Optional Ethernet backhaul work together to link Deco units to provide seamless coverage AI-Driven Mesh Intelligently learns the network environment to provide ideal Wi-Fi unique to your home 3× Antennas (Internal) Multiple antennas form a signal-boosting array to cover more directions and large areas |
| Wi-Fi capacity |
High Dual-Band Distribute devices to different bands for optimal performance 2×2 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple WiFi 6 clients 4 Streams More than enough bandwidth for connected devices |
| Operation mode |
Router Mode Access Point Mode |
| security | |
|---|---|
| Internet security |
SPI Firewall Access Control HomeShield Security Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner |
| guest network |
1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
| Wi-Fi encryption |
WPA-Personal WPA2-Personal WPA3-Personal |
| Hardware specifications | |
|---|---|
| button | Reset Button |
| network hole |
2× 2.5 Gbps Ports *Per Deco Unit Supports WAN/LAN auto-sensing |
| software | |
|---|---|
| protocol |
IPv4 IPv6 |
| Service tools | HomeShield |
| Parental supervision |
HomeShield Parental Controls Custom Profiles Professional Content Filter Library Family Time Bedtime Off Time Time Rewards Family Online Time Ranking Pause the Internet Weekly and Monthly Reports |
| WAN type |
Dynamic IP Static IP PPPoE PPTP L2TP |
| Service quality |
HomeShield QoS QoS by Device |
| Cloud services |
OTA Firmware Upgrade TP-Link ID DDNS |
| NAT forwarding |
Port Forwarding UPnP |
| IPTV |
IGMP Proxy IGMP Snooping Bridge Tag VLAN |
| DHCP |
Address Reservation DHCP Client List Server |
| DDNS | TP-Link |
| manage | Deco App |
| test data | |
|---|---|
| Wi-Fi transmission power |
CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz) <30 dBm (5 GHz) |
| entity | |
|---|---|
| Volume(W×D×H) |
4.33 × 4.33 × 4.49 in (110 × 110 × 114 mm) |
| Packaging contents |
Deco X50 Pro(1-pack) 1 Deco X50 Pro unit 1 RJ45 Ethernet cable 1 Power adapter Quick Installation Guide Deco X50 Pro(2-pack) 2 Deco X50 Pro units 1 RJ45 Ethernet cable 2 Power adapters Quick Installation Guide Deco X50 Pro ( 3-pack) 3 Deco X50 Pro units 1 RJ45 Ethernet cable 3 Power adapters Quick Installation Guide |
| Other specifications | |
|---|---|
| Certification | CE, FCC, RoHS, RCM |
| environment |
Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non- Condensing Storage Humidity: 5%~90% non-condensing |
