Description
Basic specifications
- Print mode thermal
- Resolution 203 dpi
- Printing speed 2,3,4,5 ips. 2,3 ips for peel model
- Printing width 2.13 (54mm)
- Print length 90" (2286mm)
Memory
- Memory 4MB Flash, 8MB SDRAM, Micro SD up to 4G extension
Paper specifications
- Paper width 0.6~2.36 (15~60mm)
- Paper thickness 0.06~0.19mm (2.37~7.4mil), max 150 g/m²
- Paper outer diameter 5" (127mm)OD
paper sensor
- Paper sensor transmissive/reflective
communication interface
- Communication interface USB+RS232+Ethernet(Option)
Font
-
Eight dot matrix alphanumeric fonts
Monotype vector font engine and CG Triumvirate Bold Condensed scalable font vector font can be downloaded and used as Windows fonts
programming language
- Programming language TSPL-EZ
Barcode type
-
Barcode types : One-dimensional barcode:
Code39, Code 93, Code 128UCC, Code128 subsets ABC, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on , MSI, PLESSEY, POSTNET, China POST, RSS-14, Code 11
QR code:
PDF-417, Maxicode, DataMatrix, QR code, Aztec
power supply
- Power supply 100-240V
operating environment
-
Operating temperature 5° C ~
40°C - Operating humidity 25%~85%
Certification
- CertificationFCC Class B, CE Class B, C-Tick Class B, UL, CUL, TÜV, CCC,
Machine specifications
- Machine dimensions W 109 mm x H 210 mm x D 260 mm
- Machine weight 1.2 kg
Optional equipment
- Optional accessories: cutter, paper peeler, stand-alone operation keyboard, Ethernet module
