[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4
[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4
[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4
[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4
在圖片上滾動放大 點擊圖片以放大
[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4
[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4
[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4
[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4

[請詢價] APC Easy UPS 3S 20kVA 400V 3:3 UPS High + 2 Standard battery -E3SUPS20KHB+(2)E3SBT4

APC
價格:
HK$99,999.00

描述

Specifications

Overview
Presentation High-efficiency 3-phase UPS that features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room. This is an exceptionally easy to install, operate, maintain, and service 30 kVA UPS, ideal for small and medium businesses. Includes dust filter and conformance-coated boards for harsh environments. This UPS is supplied without batteries, so you can easily customize the battery solution.
Lead time Usually Ships within 6 Weeks
Main
Main Input Voltage 400 V 3 phases
Other Input Voltage 380 V
415 V
Main Output Voltage 400 V 3 phases
Other Output Voltage 380 V
415 V
Rated power in W 30 kW
Rated power in VA 30 kVA
Provided equipment Dust filter
Installation guide
Batteries & Runtime
Efficiency View Efficiency Graph
action_new_window
Battery type External battery system
Maximum short-circuit current 10 kA
Number of battery filled slots 0
Number of battery free slots 0
Physical
Colour White (RAL 9003)
height 77 cm
Width 25 cm
Depth 80 cm
Net weight 60 kg
USB compatible Yes
Input
Maximum input current 55 A
Load power factor 0.9 leading to 0.9 lagging
Input Power Factor at Full Load 0.99
Input voltage limits 304...477 V
Network frequency 45...65 Hz
Output
Maximum configurable power in VA 30 kVA
Maximum configurable power in W 30 kW
Output frequency 50 Hz sync to mains
60 Hz sync to mains
Harmonic distortion Less than 3 %
Output overload operation 10 minutes at 125% and 60 seconds at 150%
UPS type Double conversion online
bypass type Built-in maintenance bypass
Crest factor 3 : 1
Conformance
product certifications CE
EAC
RCM
Environmental
Ambient air temperature for operation 0…40 °C
Relative humidity 0…95 % non-condensing
Operating altitude 0...3281 ft
Ambient air temperature for storage -15…40 °C
Storage Relative Humidity 0…95 % non-condensing
Storage altitude 0.00…14999.82 m
Acoustic level 63 dBA
heat dissipation 1410 W
IP degree of protection IP20
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 101.5 cm
Package 1 Width 98.2 cm
Package 1 Length 40 cm
Package 1 Weight 77 kg
Contractual warranty
Warranty 1 year on-site repair or replace with factory authorized Start-Up
