APC
價格:
HK$39,800.00 HK$42,305.00

描述

Specifications

Overview
Presentation High density, double-conversion on-line power protection with scalable runtime.
Lead time Usually in Stock
Main
Run time for load
W
information_stroke

Min-max: 450-4500 W
3min 59s
Max. Capacity Used
information_stroke
100 %


Main Input Voltage 230 V
Other Input Voltage 220 V
240 V
Main Output Voltage 230 V
Other Output Voltage 220 V
240 V
Rated power in W 4500 W
Rated power in VA 5000 VA
output connection type 6 IEC 60320 C13
2 IEC Jumpers
4 IEC 60320 C19
Number of rack unit 3U
Provided equipment Documentation CD
Installation guide
Rack mounting hardware
Rack mounting brackets
Rack mounting support rails
Temperature probe
Warranty card
Web/SNMP management card
Batteries & Runtime
Run Time View Runtime Graph
action_new_window
Efficiency View Efficiency Graph
action_new_window
Battery type Lead-acid battery
Number of battery filled slots 0
Battery recharge time 1.5 h
Number of battery replacement quantity 1
Battery voltage 192 V
Battery charger power 560 W rated
Battery life 3…5 year(s)
Extended runtime 1
General
UPS type Double conversion online
product web sub-family High density
Number of power module free slots 0
Number of power module filled slots 0
Redundant No
Physical
Colour Black
height 13 cm
Width 43.2 cm
Depth 71.94 cm
Net weight 54.43 kg
Mounting location Front
Mounting preference No preference
Mounting mode Rack-mounted
Two post mountable 0
USB compatible Yes
Mounting position Horizontal
Input
Network frequency 40...70 Hz auto-sensing
Number of input connectors 1 hard wire 3-wire (1P + N + E)
Input voltage limits 100...275 V adjustable (half load)
Output
Maximum configurable power in VA 5000 VA
Maximum configurable power in W 4500 W
Output frequency 50/60 Hz +/- 3 Hz sync to mains
Wave type Sine wave
Harmonic distortion Less than 2 %
Crest factor 3 : 1
bypass type Internal bypass (automatic and manual)
Conformance
product certifications CE
EAC
IRAM
RCM
VDE
Marking CE Mark
Standards EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018
Environmental
Ambient air temperature for operation 0…40 °C
Relative humidity 0…95 % non-condensing
Operating altitude 0...10000 ft
Ambient air temperature for storage -15…45 °C
Storage Relative Humidity 0…95 % non-condensing
Storage altitude 0.00…15240.00 m
Acoustic level 55 dBA
heat dissipation 931 Btu/h
IP degree of protection IP20
Communications & Management
Free slots 1
Preinstalled device Network management card 3 with environmental monitoring
Alarm Audible and visible alarms : prioritized by severity
Emergency power off Yes
Surge Protection and Filtering
Surge energy rate 480 J
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 33 cm
Package 1 Width 61 cm
Package 1 Length 96 cm
Package 1 Weight 66.86 kg
Contractual warranty
Warranty 3 years repair or replace (excluding battery) and 2 years for battery
