描述
| Model | CSK550DC | |
| Safe Model | X5000A533XC-24 | |
| Type | ATX 12V 2.52 | |
| Dimension | 140(L)*150(W)*86(H) | |
| Modular | Non-Modular | |
| Warranty | 5 years | |
| Input Voltage | 100V-240V | |
| Input Current | 12A Max | |
| Input Frequency Range | 50Hz-60Hz | |
| PFC | Active PFC | |
| Power Good Signal | 100-500ms | |
| Protection | OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO | |
| Output Capacity | 550W | |
| Operation Temperature | 0~40°C | |
| Regulatory | cTUVus / TUV / CB / RCM / CE / FCC / BSMI / KC / UKCA / ICES/BIS |
|
| Fan | 120mm Silent Fan | |
| Certifications | 80 Plus Bronze | |
| Connector | 1 x 24(20+4)pin MB | |
| 2 x 8(4+4)pin CPU | ||
| 2 x 8(6+2)pin PCI-E | ||
| 6 x SATA | ||
| 3 x Molex | ||
| Unit Box Dimensions | 255mm(L)*195mm(W)*100mm(H) | |
| Shipping Box Dimensions | 545mm(L)*425mm(W)*230mm(H) | |
| Net Weight | 1.60KG | |
| Gross Weight | 1.90KG | |
