Product NumberBlack: NR100-KNNN-S00, White: NR100-WNNN-S00
Exterior ColorBlack, White
Materials - ExteriorSteel, Plastic, Aluminum
Materials - Side PanelAluminum
Motherboard SupportITX
Graphic Card SupportTriple Slot 336 mm length and 140 mm height (PCIe slot can be adjusted for 356 mm GPU length)
Expansion Slots2x PCIe Slot Mounting
Drive Bays - 2.5" SSD1
I/O Panel - USB Ports2x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2x2 Type-C
I/O Panel1x Audio Combo (Audio In / Out 3.5mm)
Clearances - CPU Cooler50 / 70mm
Clearances - Power Supply100mm
Clearances - RAM50 / 70mm
Clearances - Graphics Card50mm CPU Cooler: 337 x 62 x 180mm / 357 x 79 x 180mm (expansion) (max. space incl. GPU power connector), 70 mm CPU Cooler: 337 x 42 x 180mm / 357 x 59 x 180mm (expansion) (max. space incl. GPU power connector)
Pre-installed Fan(s) - Top120mm CS120 PWM Fan (max. 1200 RPM)
Pre-installed Fan(s) - Rear120mm CS120 PWM Fan (max. 1200 RPM)
Dust FiltersSide panels
Cable Routing - Behind MB Tray11mm
Power Supply SupportSFX
Included Accessories1x 240 PCIe 4.0 x 16 Riser Cable, 1x ATX 3.0 power cable for vertical mount
Volume14.7L / 16.4L (incl. protrusions)
Dimensions (L x W x H)155 x 212 x 449mm / 172 x 212 x 449mm (Incl. Protrusions), 155 x 212 x 425mm / 172 x 212 x 425mm (Excl. Protrusions)
Warranty2 years
SizeMini ITX
