描述
Physical
| Socket: | Intel Socket 1700 |
|---|---|
| Foundry: | Intel |
| Process Size: | 10 nm |
| Die Size: | 257 mm² |
| Package: | FC-LGA16A |
| tJMax: | 100°C |
Processor
| Market: | Desktop |
|---|---|
| Production Status: | unreleased |
| Release Date: | Unknown |
| Part#: | unknown |
| Bundled Cooler: | None |
Performance
| Frequency: | 3.4 GHz |
|---|---|
| Turbo Clock: | up to 5.6 GHz |
| P-Core Turbo: | 5.5 GHz |
| P-Core Boost 3.0: | 5.6 GHz |
| E-Core Frequency: | 2.5 GHz up to 4.3 GHz |
| Base Clock: | 100 MHz |
| Multiplier: | 34.0x |
| Multiplier Unlocked: | Yes |
| TDP: | 125 W |
| PL1: | 253 W |
| PL2: | 253 W |
| PL2 Tau Limit: | Unlimited |
Architecture
| Codename: | Raptor Lake-R |
|---|---|
| Generation: |
Core i7 (Raptor Lake Refresh) |
| Memory Support: | DDR4, DDR5 |
| DDR4 Speed: | 3200 MT/s |
| DDR5 Speed: | 6000 MT/s |
| Memory Bus: | Dual-channel |
| ECC Memory: | Yes |
| PCI-Express: | Gen 5, 20 Lanes (CPU only) |
| Secondary PCIe: | Gen 4, 4 Lanes |
| Chipsets: | Intel 600 Series, Intel 700 series |
Core Config
| # of Cores: | 20 |
|---|---|
| # of Threads: | 28 |
| Hybrid Cores: | P-Cores: 8 E-Cores: 12 |
| SMP # CPUs: | 1 |
| Integrated Graphics: | UHD Graphics 770 |
Cache
| Cache L1: | 80 KB (per core) |
|---|---|
| Cache L2: | 2 MB (per core) |
| Cache L3: | 33 MB (shared) |
| E-Core L1: | 96 KB (per core) |
| E-Core L2: | 4 MB (per module) |
Features
|
