描述
| Product Name | O11 Dynamic MINI |
| MODEL | O11D Mini-S |
| COLOR | Snow white |
| DIMENSIONS | (D)420mm X (W)269.5mm X (H)380mm |
| MOTHERBOARD | E-ATX (Max 280 mm wide)/ATX/ Micro-ATX/ Mini-ITX |
| PSU | SFX/ SFX-L |
| MATERIAL | Steel 4 mm Tempered Glass 2mm Aluminum (top and left panel) |
| FAN SUPPORT | Top: 3x 120mm or 2x 140mm Side: 2x 120mm or 2x 140mm Bottom: 3x 120mm or 2x 140mm Rear: 1x 120mm |
| RADIATOR SUPPORT | Top: 360mm or 280mm or 240mm or can’t mount Side: 240mm or 280mm radiator Bottom: 360 or 280mm or 240mm radiator |
| GPU LENGTH CLEARANCE | 395mm |
| CPU COOLER HEIGHT CLEARANCE | 170mm |
| VGA Length | 370mm |
| DRIVES | Right side 2 x 2.5″ SSD + back plate 2 x 3.5″ HDD (or SSD) |
| EXPANSION SLOTS | 3 or 5 or 7 slots (depends on back panel) |
| IO PORTS | 2 x USB 3.0, 1 x USB 3.1 TYPE-C, 1 x HD Audio, Power Button |
| DUST FILTERS | 1 x Top, 1 x Bottom, 2 x Side |
