Technical Specifications
Power Consumption
- 3.83 W / 7.0 W
LEDs
- Link, speed, activity, and PoE indicators
Dimensions (LxWxH)
- 210 x 104 x 25 mm (8.3 x 4.1 x 1.0 in.)
Weight
- 0.50 kg (1.10 lbs)
Minimum System Requirements
- Connected devices need Ethernet connectivity and Ethernet cables
Operating Humidity
- 10–90% (non-condensing)
Operating Temperature
- 0–50°C (32–122°F)
Ports
- 8-port switch with 4 PoE+ ports (first 1–4 ports) and dedicated PoE power budget of 50 W
Mounting
- Wall
Quality Of Service
- 802.1p and DSCP
Storage Temperature
- -40–70°C (-40–158°F)
Warranty and Support
- 5 Year Warranty
MAC Address Table Size
- 8,000 entries
Performance
- 0.01488 Mpps for 10M port
- 0.1488 Mpps for 100M port
- 1.488 Mpps for 1000M port
- Full line rate and forwarding rate of 64B frame at:
Power
- 54 VDC, 1.2 A
Regulatory Compliance
- FCC Class A, CE
Maximum Power Consumption
- 1.71 W / 5.08 W
Fans
- None
Storage Humidity
- 10–90% (non-condensing)
Power Saving
- Cable connected detection, sleep mode
Network Standards
- IEEE 802.3
- IEEE 802.3ab
- IEEE 802.3af
- IEEE 802.3at (PoE+)
- IEEE 802.3az
- IEEE 802.3u
- IEEE 802.3x
Bandwidth
- 16 Gbps (non-blocking)
