Technical Specifications
Power Consumption
- 2.36W/8.01W
LEDs
- Link, speed, and activity indicators
Dimensions (LxWxH)
- 288 x 102 x 26 mm
Weight
- 0.703 kg
Minimum System Requirements
- Connected devices need Ethernet connectivity and Ethernet cables
Operating Humidity
- 10–90% (non-condensing)
Operating Temperature
- 0–50°C
Ports
- 16 Gigabit Ethernet (10/100/1000) Ports
Quality Of Service
- 802.1p and DSCP
Storage Temperature
- -40–70°C
Warranty and Support
- 5 Year Warranty
MAC Address Table Size
- 8K
Performance
- 0.01488Mpps for 10M port
- 0.1488Mpps for 100M port
- 1.488Mpps for 1000M port
- Full line rate and forwarding rate of 64B frame at:
Power
- 12 VDC, 1 A
Regulatory Compliance
- FCC Class B, CE
Fans
- None
Power Consumption
- 2.66 W / 9.32 W
Storage Humidity
- 10–90% (non-condensing)
Power Saving
- Cable connected detection, sleep mode
Network Standards
- IEEE 802.3
- IEEE 802.3ab
- IEEE 802.3az
- IEEE 802.3u
- IEEE 802.3x
Bandwidth
- 32 Gbps (non-blocking)
