FAN Specification
Size
120x120x25 mm
Mounting hole spacing
105x105 mm
Cable length
20cm + 30cm NA-EC1 extension cable
Rotational speed (+/- 10%)
800 RPM
Rotational speed with L.N.A. (+/- 10%)
600 RPM
Acoustical noise
8,6 dB(A)
Acoustical noise with L.N.A.
6,7 dB(A)
Static pressure
0,62 mm H₂O
Static pressure with L.N.A.
0,44 mm H₂O
Input power (typical)
0,264 W
Input power (max.)
0,72 W
Input current (typical)
0,022 A
Max. input current
0,06 A
Operating voltage
12 V
MTTF
> 150.000 h
Scope of delivery
- Low-Noise Adaptor (L.N.A.)
- 3:4 Pin Adaptor
- 30cm Extension Cable
- 4 Vibration-Compensators
- 4 Fan Screws
