Specifications
| Brand | NZXT |
|---|---|
| Model | CM-H72FB-01 |
| Type | ATX Mid Tower |
|---|---|
| Color | Black |
| Case Material | SGCC Steel, Dark Tinted Tempered Glass |
| Motherboard Compatibility | E-ATX (Up to 27.7mm), ATX, Micro-ATX, Mini-ITX |
| Dust Filters | High Performance Mesh |
| Internal 3.5" Drive Bays | 2 + 2 |
|---|---|
| Internal 2.5" Drive Bays | 4 |
| Expansion Slots | 7 |
| Front Ports | 2x USB 3.2 Gen 1 Type-A 1 x USB 3.2 Gen 2 Type-C 1 x Headset Audio Jack |
|---|
| Fan Options | Front: 3 x 120 mm / 3 x 140 mm (3 x F120Q included) Top: 3 x 120 mm / 2 x 140 mm Bottom: 3 x 120 mm Rear: 1 x 120 mm / 1 x 140 mm Fan Specs Model: F120Q Airflow Fan (Case Version) Speed: 1,350 ± 150 RPM Airflow: 60.2 CFM Static Pressure: 1.05 mm-H2O Noise: 24.1 dBA Fan Connector: 3-pin |
|---|---|
| Radiator Options | Front: Up to 420 mm Top: Up to 360 mm Rear: Up to 140 mm |
| Max GPU Length | 410 mm |
|---|---|
| Max CPU Cooler Height | 185 mm |
| Max PSU Length | 200 mm |
| Dimensions (H x W x D) | W: 244mm H: 544mm D: 468mm (with feet) |
