Affordable High-Speed Network Environment
Five 2.5GbE ports support existing devices and are ready for next-generation 2.5GbE devices. Providing home or office users easy plug-and-play for faster and smoother productivity and entertainment.
Loop Detection and Blocking
The QSW-1105-5T features network loop detection. If a network loop is detected, the QSW-1105-5T automatically locks the looped ports to ensure the network environment quickly resumes normal operation.
Cool and Quiet Operation
The QSW-1105-5T features a fanless design for near-silent operation. The unique ventilated construction assists in cooling while maintaining high performance.
| management type | No management |
| Number of ports | 5 |
| 2.5GbE (RJ45) | 5 |
| Power supply description | power adapter |
| Maximum power consumption | 12 W |
| Input power type | DC |
| Input voltage range | 12V |
| MAC address table | 16K |
| Total congestion-free traffic | 12.5Gbps |
| switching capacity | 25Gbps |
| fan | fanless |
| fanless | |
| Support standards |
IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5GBase-T IEEE 802.3x full-duplex flow control |
| Appearance | PC version |
| LED indicator |
Per Port: Speed/Link/Activity Loop LED: Loop Per System: Power/Status |
| Dimensions (height x width x depth) | 34x180x145mm |
| Weight (net weight) | 0.577kg |
| operating temperature | 0°C to 40°C (32°F to 104°F) |
| relative humidity | 10% to 90% (non-condensing) |
| certificate | FCC, CE, BSMI, VCCI, LVD, CCC, KCC, ASNZ |
| Electromagnetic Code | Class B |
| Jumbo Frame Packet | 9k |
| Warranty | 2 years |
