| P/N |
PS-TPD-750FNFAGx-H |
| WATTS |
750W |
| MODEL |
TTP-750AH2FKG |
| MAX. OUTPUT CAPACITY |
750W |
| COLOR |
Black |
| DIMENSION ( W / H / D ) |
150mm(W)x86mm(H)x140mm(D) |
| PFC (POWER FACTOR CORRECTION) |
Active PFC |
| POWER GOOD SIGNAL |
100-250 msec |
| HOLD UP TIME |
> 17msec |
| INPUT CURRENT |
10A Max. |
| INPUT FREQUENCY RANGE |
50Hz - 60Hz |
| INPUT VOLTAGE |
100 - 240Vac |
| OPERATING TEMPERATURE |
0°C to + 45°C |
| OPERATING HUMIDITY |
5% to 85%,non-condensing |
| STORAGE TEMPERATURE |
-40°C to + 70°C
|
| STORAGE HUMIDITY |
5% to 95%, non-condensing |
| COOLING SYSTEM |
12cm FDB Fan |
| EFFICIENCY |
Meet 80 PLUS® Gold at 115Vac input. |
| MTBF |
100,000 hrs minimum |
| SAFETY APPROVAL |
CE/FCC/UKCA/ICES/LVD/TUV/cTUVus/CB/CCC/BSMI |
| PCI-E 6+2PIN |
4 |
| PCIE 12+4PIN |
1(300W) |
