| P/N |
PS-TPT-0850FNFAG*-3
|
| watts |
850W |
| WATTS |
TPD-850AH2FXG-3 |
| Max. Output Capacity |
850W |
| Color |
Black |
| Dimension ( W / H / D ) |
150mm(W)x86mm(H)x140mm(D) |
| PFC (Power Factor Correction) |
Active PFC |
| Power Good Signal |
100-250 msec |
| Hold Up Time |
> 17msec at 80% load |
| Input Current |
10A Max.
|
| Input Frequency Range |
50Hz-60Hz |
| Input Voltage |
100-240V～ |
| OPERATING TEMPERATURE |
0°C to + 40°C |
| Operating Humidity |
5% to 85%,non-condensing |
| Storage Temperature |
-40°C to + 70°C |
| Storage Humidity |
5% to 95%, non-condensing |
| COOLING SYSTEM |
12cm Hydraulic bearing fan |
| Efficiency |
Meet 80 PLUS® Gold at 115Vac input. |
| MTBF |
100,000 hrs minimum
|
| Safety Approval |
CE/UKCA/ICES/TUV/LVD/RCM/CB/FCC/cTUVus/BSMI/CCC/BIS/S-MARK
|
| PCI-E 6+2pin |
4 |
| PCIe 12+4pin |
1 |
| PROTECTION |
OVP/UVP/OCP/OPP/OTP/SCP |
