Highlights
- 100 Gbps data transmission
- QSFP28 connector on both sides
- Up to 1 m transmission distance
- Wide operating temperature
- Hot Swappable
Specifications
| GENERAL | |
|---|---|
| Product Dimensions | • Plug: 2.85*0.72*0.53 in (72.45*18.35*13.50 mm); • Overall length: 39.37 in (1,000 mm) |
| SFP28 Cable | |
|---|---|
| Environment | • Operating Temperature: 0–70 ℃ (32–158 ℉) • Storage Temperature: -40–85 ℃ (-40–185 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
| Supported Data Rate | 100 Gbps / 40 Gbps |
| Conductor | Silver Plated Copper |
| Wire Gauge | 30AWG |
| Minimum Bend Radius | 33 mm |
| Cable Length | 1 m |
